Model: LE-C775, Pneumatic Chamfering Machine Metal Burr Trimming

Model: LE-C775
Minimum Radius:4mm
Minimum Hole Diameter for Chamfering:Ø 8 mm
Minimum chamfering Depth:6mm
Free Speed: 20000 r.p.m
Chamfer Angle: 45 degree
Chamfering Capacity: 0C~1C
Air Consumption: 22 SCFM
Air Inlet: 1/4"
Pressure ( bar ) : 6.2
Exhaust: Front
Weight: 0.55 kg
Length: 100 mm
Height: 88 mm

Pneumatic chamfering is a cutting tool that creates a bevel or chamfer on a workpiece. The tool uses compressed air to drive a rotating cutting head that removes material from the edge of the workpiece at an angle.

Here are some typical applications of pneumatic chamfering tools:

Applications:

1. Edge Deburring: The Mini Pneumatic Chamfering Machine excels at removing sharp edges and burrs from metal components, ensuring a smooth and safe finish. Perfect for creating a polished look on machined parts.
2. Chamfering: This machine achieves consistent and accurate chamfers on metal edges. It is ideal for creating beveled edges on various materials, enhancing aesthetics and functionality.
3. Weld Preparation: Streamline the welding process by preparing edges for optimal weld penetration. The chamfering machine ensures clean and uniform edges, producing high-quality weld joints.
4. Pipe and Tube Chamfering: Whether working with pipes or tubes, this pneumatic tool is perfect for chamfering the ends, providing a professional finish for plumbing, construction, or fabrication projects.
5. Sheet Metal Fabrication: The Mini Pneumatic Chamfering Machine improves the overall quality of your sheet metal projects by deburring and chamfering. It also enhances precision in your metalworking tasks.
